SAILOR 6120 SSA System
The SAILOR 6120 mini-C SSAS builds on the successful legacy of the SAILOR TT-3000SSA System, which since its introduction in 2004 has proven its worth in real world incidents, time and time again.
Like its predecessor, the SAILOR 6120 mini-C SSAS is based around a, self-contained and sealed Inmarsat mini-C terminal, housing both antenna and transceiver. This design approach has proven to be rugged and reliable regardless of vessel type and with the terminal’s 50 channel GPS module and omni-directional antenna, satellite fix and position are ensured even under the most adverse conditions.
- E-mail us, we reply swiftly!
- ManufacturerThrane & Thrane Cobham
- Manufacturer Part number406120A-00500
- Our Part number2270062
Description
Article no.: 2270062
SSAS Regulation
The SAILOR 6120 mini-C SSAS fully meets and exceeds the requirements listed in IMO MSC. 136(76) and MSC. 144(77) under SOLAS resolution XI-2/6.
This stipulates that all vessels over 500 GT are required to be fitted with a Ship Security Alert System (SSAS) to be used under pirate attacks to notify the flag state administration.
Alarms are silent, meaning that there is no audio or visual indication on the vessel that an alarm has been activated.
Included in system
- SAILOR 3027 SSA Terminal
- SAILOR 6194 Terminal Control Unit
- 30M NMEA2K Mini Device Cable
- Mini/Micro NMEA2K Tee
- 6m NMEA2K Power Cable
- SSAS button kit
- User/installation guide
Please note that NMEA2K Mini Device C cable is not part of the package – order separately.
30 m NMEA2K Mini Device Cable - 406100-944
50 m NMEA2K Mini Device Cable - 406100-945
10 m NMEA2K Mini Device Cable - 406100-946
15 m NMEA2K Mini Device Cable - 406100-947
